CHAOS BMW K+DCAN INPA OBD2 USB Cable

$42.00
On Sale
was $49.99 Save 16%
Android OTG Adapter
Please choose
Confirm
In stock: 106 available
Product Details
Brand: Chaos Calibrations

IN STOCK

Our own BMW K+DCAN INPA OBD2 USB Cables has arrived! The Chaos K+DCAN Cable!

One of the best K+DCAN cables on the market with unapparelled service and attention!

At an affordable price, our cables can reliably and quickly flash DMEs and modules in which cheap ebay/amazon cables can not. This is the cable required to communicate to the standard BMW OBD Interface with your laptop (more importantly, with our tuning services) in your E38, E39, E46, E6x, E83, E85, E9x, etc.


Specifically with DMEs like MS45, MSS6x, MSS70, MSD8x, etc., which require longer flashing times, complex protocols, and faster baud rates, we saw about an 8% failure rate with cheap cables that would cause a tune upload to fail, getting the DME stuck in diagnostic mode and sometimes, bricking the DME due to a bug in the stock firmware. We wanted to offer a quality and reliable cable at a more affordable price point. You can be rest assured you are purchasing a quality and tested K+DCAN Cable.


We test all our cables in house on a bench to confirm proper communication, switch functionality, download and upload times (most importantly, reliable uploading).



With our latest tuning software version (CCFlasher Suite) and our Chaos K+DCAN Cable, we were able to match MS45 FULL BINARY upload times just like other "Pro" and "Expert" cables of ~11 minutes and PARTIAL BINARIES in under 1 minute! FULL BINARY Downloads in just about 9 minutes.

SPECIFICATIONS
  • Switch for Double K-Line - Each cable is shipped with it's switch in position for bridging pins 7 & 8. You can take note of this when it arrives.
  • Fast D-CAN and PT-CAN at 500 kbit/s
  • Slow K-CAN at 100 kbit/s
  • FTDI FT232RQ
  • Increased Flashing Speeds
  • Tested and latest cable chip updates in house with highest level of reliability and ECU/Module compatibility! (As pictured above)
  • Capable of flashing: MS41, MS42 MS43, MS45, MSS52, MSS54, MSS54HP, MSS60, MSS65, MSS70, MSV70, MSD80, MSD81 DMEs (and corresponding modules) (E38, E39, E46, E83, E85, etc.)
    E6x M5/M6 SMG (GDSMG3)
    E9x GM Auto (GM1912)
    and some F-Chassis Flashing and Coding

Put your trust in The Chaos K+DCAN Cable and not the cheap stuff!

All our baseline testing is conducted with our tuning/flash software using MS45 DME as the standard. Our cables have also been tested and proven to reliably flash MSS6x DMEs which can be found in E9x M3s and E60 M5s and will function with all support similar DMEs as mentioned above.
Please understand the nature of flashing and communicating with DMEs/Modules. We are not responsible for damaged DMEs/Modules. The process includes many variables that can be a result of user errors, anti virus software, poorly configured laptops, etc.

READ OUR TERMS/CONDITIONS/DISCLAIMERS

If you have any questions, feel free to contact us.


COMPATABILITY LIST
Software:
  • All of Chaos Calibrations CCFlasher Software and Tools
  • EDIABAS - INPA
  • ISTA
  • NCS Expert / NCS Dummy
  • Tool 32
  • DIS / SSS
  • Any other software that uses BMW OBD2 K+DCAN Interface (K-Line and CAN)
Vehicles/Hardware:
  • All BMW E Chassis / Early Model F Chassis (Including E9x M3 and E60 M5)
  • DMEs/Trans: MS41, MS42 MS43, MS45, MSS52, MSS54, MSS54HP, MSS60, MSS65, MSS70, MSV70, MSD80, MSD81, E6x M5/M6 SMG (GDSMG3), E9x GM Auto (GM1912) - Other corresponding modules of these chassis.
  • BMW 1 SERIES E81, E82, E87, E88
  • BMW 3 SERIES E30, E36, E46, E90, E91, E92, E93 *
  • BMW 5 SERIES E28, E34, E39, E60, E61 *
  • BMW 6 SERIES E24, E63, E64 *
  • BMW 7 SERIES E22, E32, E38, E65 *
  • BMW 8 SERIES E31*
  • BMW X3 – E83
  • BMW X5 E53
  • BMW X5 – E70
  • BMW X6 – E71
  • BMW Z3 – E36 *
  • BMW Z4 – E85 / E86 / E89
  • BMW Z8 – E52
  • Could also support MINI R50 / R52 / R53 / R55 / R56 / R57

    * = Pre year 2000, some models may require 20-pin round connector adapter

**NOTE FOR SHIPPING**
USPS First Class Mail does NOT come with shipping insurance. This is the most affordable way to ship these items but only offers tracking. This is longest shipping time and offers no shipping insurance. If the package is lost during shipping (very rare) there is unfortunately nothing we can do, especially if the package has left the United States of America (international orders), USPS will not be able to do anything for us..
